This column is listed under the Min. Probability Detected label in the Detection Order Table section of the Detection Order Report. Each entry in this column contains the probability-weighted percentage of used functions that are proven good as a result of the corresponding detection test having passed. The Test limits in this column are order-specific; if the detection tests were to be performed in a different order, then each test may have a different Test limit in this column (since some of that test's coverage may have been proven good by previous tests in the detection sequence).
When fault detection is calculated across the entire design (i.e., the Diagnostic Scope is set to <Entire Design>), this metric can be calculated using the following equation:
1 if the ith function is proven good (either partially or fully) as a result of detection test x passing; 0 otherwise
Pfpi
=
the partial failure probability associated with the portion of the ith function that is partially or fully proven good as a result of detection test x passing
1 if the ith function is proven good (either partially or fully) as a result of detection test x passing (this will only include functions in the specified Diagnostic Scope); 0 otherwise
Pfpi
=
the partial failure probability associated with the portion of the ith function that is partially or fully proven good as a result of detection test x passing
