In the eXpresseXpress Model topology export format, the Size column contains the coordinates used by eXpress to define the relative size of the object described in the Object, I/O Flag or Annotation column of the spreadsheet. Cells in the Location column contain comma-delimited pairs of xy coordinates, optionally surrounded by parentheses, square brackets or curly braces. The following pairs are all "legal" representations of object size:
192,192
(192,192)
[192,192]
{192,192}
Although the eXpresseXpress Model topology export uses the square brackets, the Spreadsheet Topology Import accepts any of these representations. The comma-delimited xy coordinates (x= width; y= height) represent the size of the given object relative to the other objects in the design drawing.
