You can now add a test to an existing group test without having to ungroup it. In the Test Set editing mode, simply highlight the group test and the test you wish to add to the group. Then, click on the Group Test icon.
The Create Group Test dialog will appear, with the “Create New Group from Test(s)” option selected. Select the new “Add Test(s) to Existing Group(s)” option and click on the Create button. All selected non-group tests will be automatically added to all selected group tests.
Note: This feature is only enabled when one or more group tests and one or more non-group tests are selected. It therefore cannot be used to add a group test to another group test.
Note the checkbox "Remove Highlighted Tests". This checkbox allows the operator to remove the tests included in the combination test or keep these test for other usage. A typical example is where you are using the combination "Brake Assy Detection" test for detection but using the "Reduced Anti-Lock Braking Efficiency" and "Reduced Normal Braking Efficiency" in a separate test set marked for Isolation to break down the Ambiguity of the combination test Detected fault into smaller ambiguity sets.
